Specifications
| Geometrical & Mechanical |
| Core Diameter |
8.2 μm |
| Cladding Diameter |
125 ± 0.7 μm |
| Coating Diameter |
242 ± 5 μm |
| Core-Clad Concentricity |
≤0.5 μm |
| Coating-Clad Concentricity |
<12 μm |
| Fiber Curl |
≥4.0 m Radius of Curvature |
| Operating Temperature |
-60 to 85 ℃ |
| Proof Test Level (245 coat) |
≥100 kpsi (0.7 GN/m2) |
| Jacket |
Ø900 µm Hytrel |
| |
|
| Optical |
| Numerical Aperture (nominal) |
0.14 |
| Attenuation* |
≤0.32 dB/km @ 1310 nm
≤0.32 dB/km @ 1383 nm**
≤0.21 dB/km @ 1490 nm
≤0.18 dB/km @ 1550 nm
≤0.20 dB/km @ 1625 nm |
| Operating Wavelength |
1260 - 1625 nm |
| |
|
| Mode Field Diameter |
9.2 ± 0.4 μm @ 1310 nm
10.4 ± 0.5 μm @ 1550 nm |
| Dispersion |
≤18.0 ps/(nm·km) @ 1550 nm
≤22.0 ps/(nm·km) @ 1625 nm |
| Polarization Mode Dispersion,Link Design Value |
≤0.04 ps/√km |
| Polarization Mode Dispersion,Maximum Individual Fiber |
≤0.1 ps/√km |
| Bend Loss for 100 Turns on 25mm Mandrel |
≤0.01 dB @ 1550 nm |
|
*Maximum specified attenuation value available within the stated ranges.
** Attenuation values at this wavelength represent post-hydrogen aging performance.
