| Geometrical & Mechanical | |
| Cladding Diameter | 125 ± 0.5 μm |
| Coating Diameter | 245 ± 10 μm |
| Core to Cladding Offset | ≤0.3 μm |
| Operating Temperature | -60 to 85 ℃ |
| Proof Test Level | 200 kpsi |
| Jacket | Ø900 µm Hytrel |
| Optical | |
| Numerical Aperture (Nominal) | 0.14 |
| Attenuation | 2.1 dB/km @ 980 nm 1.5 dB/km @ 1060 nm |
| Operating Wavelength | 980 – 1650 nm |
| Cut-Off Wavelength | 920 ± 50 nm |
| Mode Field Diameter | 5.9 ± 0.3 μm @ 980 nm 6.2 ± 0.3 μm @ 1060 nm |
