| 0.22 NA Hard Cladding, Silica Core, Multimode Fiber | |
| Wavelength Range | 400 – 2400 nm (Low OH) 250 – 1200 nm (High OH)a |
| Core / Cladding | Pure Silica / Fluorine-Doped Silica |
| Coating | Acrylate |
| Proof Test | ≥100 kpsi |
| Operating Temperature | -40 to 85 °C |
| Numerical Aperture (NA) | 0.22 ± 0.02 |
| Bandwidth @ 820 nm | 15 MHz•km |
| a. Solarization may occur at wavelengths below 300 nm | |
